14*2 1d 2d 3d Screw Coil Insert Helicoil Inserts Ss

Xinxiang Flight Fasteners Co., Ltd.
Contact Now

14*2 1d 2d 3d Screw Coil Insert Helicoil Inserts Ss

  • 1
  • 2

Brand Name : Flight

Model Number : 304 316 321

Certification : ISO9001:2015 TS16949

Place of Origin : China

MOQ : MOQ100

Price : By actual calculation

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 20000000 PCs /year

Delivery Time : 15 days

Packaging Details : Plastic bag or carton

Material : Stainless Steel, stainless steel

Type : M14

Size : 14*2

Product name : wire thread insert

Grade : SUS304

Contact Now

14*2 1d 2d 3d Wholesaler China Shop Screw Coil Insert Helicoils Inserts Ss



Information

Threaded Inserts are cylindrical, metal bushings with features on the outside which lock them into a plastic or metal base material to anchor your fasteners. Our Threaded Inserts provide high-quality, permanent, wear-resistant internal threads and are designed to be installed in molded or drilled holes in one simple step. While each style performs in a range of materials, they are generally classified by method of installation: Thread-Cutting, Thread-Forming, Push-In, or Ultrasound.Threaded Inserts are cylindrical, metal bushings with features on the outside which lock them into a plastic or metal base material to anchor your fasteners. Our Threaded Inserts provide high-quality, permanent, wear-resistant internal threads and are designed to be installed in molded or drilled holes in one simple step. While each style performs in a range of materials, they are generally classified by method of installation: Thread-Cutting, Thread-Forming, Push-In, or Ultrasound.

Materials Brass,Stainless Steel,Carbon steel1215,Other materials
Finish Zn/Ni/Tin/Au plating,Black Oxide,Anodizing,Passivated and so on.
Type Wire thread insert/Keylocking threaded insert/Solid threaded insert
Thread Internal thread A:as per ISO6H
Certification ISO9001:2015
Lead Time 5-10 working days
Samples Welcome

Thread inserts parameter

Options
Material 304H 321 316 Inconel X750
Standard DIN-8140 MS-21209
Model Metric M3 M4 M5 M6 M8 M10 M12 M16
British 6-32 8-32 10-32 1/4-20 1/2-13 5/8-11
Length 1d 1.5d 2d
Accuracy Green Red Golden Blue Non Customized


DIMENSION OF DIN8140 WIRE THREAD INSERTS
D P L1 d1 D P L1 d1
min max min max
M2 0.4 1d 2.6 2.8 M8 1.25 2d 9.85 10.1
1.5d 2.5d
2d M10 1.5 1d 12.1 12.5
2.5d 1.5d
M2.5 0.45 1d 3.3 3.5 2d
1.5d 2.5d
2d M12 1.75 1d 14.4 14.8
2.5d 1.5d
M3 0.5 1d 3.8 4 2d
1.5d 2.5d
2d M16 2 1d 19 19.4
2.5d 1.5d
M4 0.7 1d 5.15 5.35 2d
1.5d 2.5d
2d M20 2.5 1d 23.7 24.2
2.5d 1.5d
M5 0.8 1d 6.35 6.6 2d
1.5d M24 3 1d 28.6 29.1
2d 1.5d
2.5d 2d
M6 1 1d 7.6 7.85 M30 3.5 1d 35.2 35.7
1.5d 1.5d
2d 2d
2.5d M36 4 1d 42.1 42.6
M8 1.25 1d 9.85 10.1 1.5d
1.5d 2d

14*2 1d 2d 3d Screw Coil Insert Helicoil Inserts Ss

14*2 1d 2d 3d Screw Coil Insert Helicoil Inserts Ss


14*2 1d 2d 3d Screw Coil Insert Helicoil Inserts Ss
14*2 1d 2d 3d Screw Coil Insert Helicoil Inserts Ss
14*2 1d 2d 3d Screw Coil Insert Helicoil Inserts Ss


FAQ

Q: Are you trading company or manufacturer ?

A: We are factory.

Q: How long is your delivery time?

A: Generally it is 3 days if the goods are in stock. or it is7days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
